Product details
The JARIFA² combines MTB and trekking DNA. The cockpit with a 30-degree stem and ergonomic parts make your ride comfortable even on rides off the beaten track. The C.I.S. (Cockpit Integration Solution) technology offers a clean cockpit with cable routing through stem and headset into the frame. Additionally, the JARIFA² can be retrofitted easily thanks to respective mounting points. On top, the JARIFA² 6.8 is approved for most trailers and for a system weight (rider plus gear and bike) of 150 kg.
JARIFA² 6.8 FEATURES
- CUSTOMISABLE BOSCH SMART SYSTEM WITH PERFORMANCE CX E-DRIVE, KIOX 300 DISPLAY AND 750 (SIZE XS AND S: 625) WH BATTERY
- OFFROAD-READY MOUNTAIN BIKE GEOMETRY WITH 29" WHEELS (SIZE XS: 27,5") AND SHIMANO DEORE 11-SPEED SHIFTING
- COMFORTABLE COCKPIT, C.I.S. STEM WITH INTEGRATED CABLE ROUTING AND SUNTOUR AIR SUSPENSION FORK
ESCAPE THE DAILY GRIND
-
SUPER POWERFUL AND DYNAMIC E-MOTOR
The efficient Bosch Performance CX e-drive (Gen. 4) supports your ride up to 25 km/h with powerful 85 Nm. A well-balanced geometry makes the JARIFA² ride agile and dynamic. The strongest e-motor of Bosch is perfectly integrated into the bottom bracket area.
-
RECORD-BREAKING INTEGRATED RANGE AND A NEW DISPLAY
The new Bosch Powertube battery (smart system) with its record-breaking 750 Wh (size XS & S: 625 Wh) is perfectly integrated into the down tube, yet it can also be removed at any time for charging. Furthermore, the latest Kiox 300 offers a bigger, easier-to-read display with a new remote and better ergonomics. Additionally, a USB-C port on the top tube gives you the opportunity to charge your devices.
-
EXTRA-COMFORTABLE, INTEGRATED AND EASY TO RETROFIT
The JARIFA² combines MTB and trekking DNA. The cockpit with a 30-degree stem and ergonomic parts make your ride comfortable even on rides off the beaten track. The C.I.S. (Cockpit Integration Solution) technology offers a clean cockpit with cable routing through stem and headset into the frame. Additionally, the JARIFA² can be retrofitted easily thanks to respective mounting points. On top, the JARIFA² 6.8 is approved for most trailers and for a system weight (rider plus gear and bike) of 150 kg. Considering the needs of smaller riders, the JARIFA² models in size XS roll on 27,5" wheels.
The JARIFA² is ideally suited for adventures off the paths. Thanks to the mountain bike geometry, it feels at home off-road. The e-hardtail encourages everyday escapes and even has mounting options for a rack, mudguards, lights and stands. With a free system weight (rider, bike and accessories like a backpack, etc.) of up to 150 kg, we make it possible for even more people to ride our bikes. You can also use a trailer for thru-axles.
SUPER POWERFUL AND DYNAMIC E-MOTOR
The efficient Bosch Performance CX e-drive (Gen. 4) supports your ride up to 25 km/h with powerful 85 Nm. The strongest e-motor of Bosch is perfectly integrated, the JAM² rides agile and nimble. In eMTB mode, the motor support adjusts automatically to your riding power. The Bosch Powertube battery is perfectly integrated into the down tube, yet it can also be removed at any time for charging. For sure, you can also charge it directly on the bike.
- Brake
- 180 mm
- Frame size
- M,L,XL,XS,S
- 44,48,52,36,40
- Drive train
- chain
- Max total weight
- 150
- Frame
- 7005 hydroformed aluminium, 3D forging, 148x12 mm thru axle, USB-C port, post mount 180 mm
- Fork
- SR Suntour XCR 34 LO Air, 15x110 mm
- Handlebar
- Aluminium, 760 mm, flatbar, backsweep: 9°, 35,0 mm
- Saddle
- Selle Royal Vivo
- Seat post
- Aluminium, 31.6 mm
- Stem
- FOCUS C.I.S. integrated, 60 mm, 30°, 35 mm, aluminium
- Brakes
- Shimano MT410, 2-piston, hydraulic disc brake,Shimano MT410, 2-piston, hydraulic disc brake
- Crank set
- FSA CK-320, aluminium
- Switch lever
- Shimano Deore M5100, 11-speed
- Sprocket
- Shimano Deore CS-M5100, 11-speed
- Transmission
- front: 36, rear: 11-51
- Headset
- ACROS ZS56/ZS66 (ICR), FOCUS C.I.S. Integrated
- Tyres
- Schwalbe Smart Sam, 29 x 2,25"
- Schwalbe Smart Sam, 27,5 x 2,25"
- Schwalbe Smart Sam , 29 x 2,25"
- Tyres, rear
- Schwalbe Smart Sam, 29 x 2,25"
- Schwalbe Smart Sam, 27,5 x 2,25"
- Schwalbe Smart Sam , 29 x 2,25"
- Wheel rims
- RODI TRYP25, 25-622,RODI TRYP25, 25-622
- specs.ProductRearBrakeDescription
- Shimano MT410, 2-piston, hydraulic disc brake
- Disc brake rotor, front
- 180 mm
- Disc brake rotor, rear
- 180 mm
- Battery
- Bosch PowerTube Li-Ion (625 Wh)
- 750 Wh,625 Wh
- Colour
- Toronto Grey
- Goldbrown
- Travel
- 100 mm
- Hub
- Shimano Alivio MT400, 15x110 mm
- Shimano Alivio MT400, 12x148 mm
- Grip
- Herrmans Click
- Rear derailleur
- Shimano Deore RD-M5100, 11-speed
- Tire
- Schwalbe Smart Sam, 29 x 2,25",Schwalbe Smart Sam, 27,5 x 2,25",Schwalbe Smart Sam , 29 x 2,25"
- Shift/brake lever
- Shimano Deore M5100, 11-speed
- Spoke
- Zink, black
- Chain
- Shimano CN-HG601, 11-speed
