Product details
KEY PERFORMANCE FACTORS
Class-leading efficiency
Combining best-in-class stiffness-to-weight with strategically placed aero tube shaping, this frameset is engineered for faster climbing, explosive acceleration and unyielding pedalling stiffness for race-winning performance.
Advanced aerodynamics
This is where the TCR’s most quantifiable gains can be found compared to previous generation models. Every tube shape was analysed, engineered and tested to create an overall structure with significantly lower drag at a wider range of yaw angles.
Total control
Integrated disc brakes deliver smooth, powerful stopping power and modulation for added control in variable weather and road conditions. Flat mounts and new thru-axles boost stiffness and improve overall handling, while added frame and fork clearance allows for larger diameter tyres up to 32mm.
SIZING GUIDE AND GEOMETRY
Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.
-
- XS: 157 cm - 169 cm
-
- S: 165 cm - 175 cm
-
- M: 171 cm - 181 cm
-
- ML: 177 cm - 187 cm
-
- L: 183 cm - 193 cm
-
- XL: 189 cm - 199 cm
-
SizesXS, S, M, M/L, L, XL
-
ColoursAirglow
-
FrameAdvanced SL-Grade Composite, integrated seatpost, disc
-
ForkAdvanced SL-Grade Composite, full-composite OverDrive 2 steerer, disc
-
ShockN/A
-
HandlebarGiant Contact SLR XS:40cm, S:40cm, M:42cm, M/L:42cm, L:44cm, XL:44cm
-
GripsStratus Lite 2.0
-
StemGiant Contact SLR XS:80mm, S:90mm, M:100mm, M/L:110mm, L:110mm, XL:120mm
-
SeatpostAdvanced SL-Grade composite, integrated design, -5/+15mm offset
-
SaddleGiant Fleet SLR
-
PedalsN/A
-
ShiftersSRAM Force eTap AXS
-
Front DerailleurSRAM Force eTap AXS
-
Rear DerailleurSRAM Force eTap AXS
-
BrakesSRAM Force eTap AXS hydraulic, SRAM CenterLine XR rotors [F]160mm, [R]140mm
-
Brake LeversSRAM Force eTap AXS hydraulic
-
CassetteSRAM Force, 12-speed, 10x33
-
ChainSRAM Force D1
-
CranksetSRAM Force D1 DUB, 35/48with Giant Power Halo power meter XS:170mm, S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm
-
Bottom BracketSRAM DUB, press fit
-
RimsGiant SLR 1 36 Carbon Disc WheelSystem, [F] 36mm, [R] 36mm
-
Hubs[F] Giant Low Friction Hub, CenterLock, 12mm thru-axle, [R] Giant Low Friction Hub, 30t ratchet driver, CenterLock, 12mm thru-axle
-
SpokesSapim CX-Ray
-
TiresCADEX Race, tubeless, 700x25c (26.5mm), folding
-
ExtrasComputer mount, tubeless prepared, 32mm max tyre size
-
WeightThe most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
