Giant 2023 Giant TCR Advanced SL Disc FF
Giant 2023 Giant TCR Advanced SL Disc FF
Sale
Giant

2023 Giant TCR Advanced SL Disc FF

•••••
+-
$4,699.00$2,399.00
Add to cart
Only a few left

Product details

Class-leading efficiency

Combining best-in-class stiffness-to-weight with strategically placed aero tube shaping, this frameset is engineered for faster climbing, explosive acceleration and unyielding pedalling stiffness for race-winning performance.

Advanced aerodynamics

This is where the TCR’s most quantifiable gains can be found compared to previous generation models. Every tube shape was analysed, engineered and tested to create an overall structure with significantly lower drag at a wider range of yaw angles.

Total control

Integrated disc brakes deliver smooth, powerful stopping power and modulation for added control in variable weather and road conditions. Flat mounts and new thru-axles boost stiffness and improve overall handling, while added frame and fork clearance allows for larger diameter tyres up to 32mm.

The limited-edition TCR Advanced SL Disc Team frameset features aero tube shaping for added efficiency, plus a Variant Integrated Seatpost to reduce weight and add road-smoothing compliance.  Here’s a look at some of the key technologies that make it the top choice for the climbers and general classification riders of Team BikeExchange-Jayco.

    XS S M ML L XL
A SEAT TUBE LENGTH (mm) 680 710 740 770 800 830
B SEAT TUBE ANGLE 74.5° 74.0° 73.5° 73.0° 73.0° 72.5°
C TOP TUBE LENGTH (mm) 520 535 550 565 580 600
D HEAD TUBE LENGTH (mm) 120 130 145 165 185 200
E HEAD TUBE ANGLE 71.0° 72.3° 73.0° 73.0° 73.0° 73.0°
F FORK RAKE (mm) 45 45 45 45 45 45
G TRAIL (mm) 72.1 64 59.2 59.2 59.2 59.2
H WHEELBASE (mm) 976 977 980 991 1006 1020
I CHAIN STAY LENGTH (mm) 405 405 405 405 405 405
J BOTTOM BRACKET DROP (mm) 72 70 70 67 67 67
K STACK (mm) 517 528 545 562 581 596
L REACH (mm) 376 383 388 393 402 412
M STAND OVER HEIGHT (mm) 706 725 747 773 800 816
O STEM LENGTH (mm) 80 90 100 110 110 120
P CRANK LENGTH (mm) 170 170 172.5 172.5 175 175
Q WHEEL SIZE 700C 700C 700C 700C 700C 700C
  • Sizes
    XS, S, M, M/L, L, XL
  • Frame
    Advanced SL-Grade Composite, integrated seatpost, disc
  • Fork
    Advanced SL-Grade Composite, full-composite OverDrive 2 steerer, disc
  • Shock
    N/A
  • Seatpost
    Advanced SL-Grade composite, integrated design, -5/+15mm offset
  • Bottom Bracket
    BB86 accepts press fit style BB only, bearing set not included
  • Extras
    Front & rear 12mm thru-axles, 20mm & 45mm ISP clamps
  • Weight
    The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.


Reviews

•••••

0 stars based on 0 reviews

Add your review
