Product details
Elite level efficiency
Advanced-grade composite frameset is 17.5 percent lighter than the previous generation while retaining its best-in-class torsional/pedalling stiffness.
Total control
Integrated disc brake technology with flat mounts and thru-axle hubs, combined with tubeless ready Giant WheelSystem, delivers added control in variable conditions and all types of weather.
Smooth ride quality
D-Fuse composite seatpost helps absorb bumps and vibrations, and you also have the option to switch to a standard 30.9mm round or dropper post depending on your riding style and terrain.
S | M | ML | L | XL | ||
---|---|---|---|---|---|---|
A | Seat Tube Length (mm) | 505 | 525 | 545 | 555 | 565 |
B | Seat Tube Angle | 73.5° | 73.0° | 73.0° | 73.0° | 73.0° |
C | Top Tube Length (mm) | 530 | 545 | 560 | 575 | 590 |
D | Head Tube Length (mm) | 133 | 148 | 163 | 178 | 193 |
E | Head Tube Angle | 71.0° | 71.5° | 72.0° | 72.5° | 72.5° |
F | Fork Rake (mm) | 50 | 50 | 50 | 50 | 50 |
G | Trail (mm) | 68.3 | 65.1 | 61.8 | 58.6 | 58.6 |
H | Wheelbase (mm) | 1014 | 1020 | 1030 | 1040 | 1055 |
I | Chain Stay Length (mm) | 430 | 430 | 430 | 430 | 430 |
J | Bottom Bracket Drop (mm) | 60 | 60 | 60 | 60 | 60 |
K | Stack (mm) | 540 | 556 | 572 | 589 | 603 |
L | Reach (mm) | 370 | 375 | 385 | 395 | 406 |
M | Stand Over Height (mm) | 788 | 807 | 826 | 832 | 845 |
O | Stem Length (mm) | 80 | 90 | 100 | 100 | 110 |
P | Crank Length (mm) | 170 | 172.5 | 172.5 | 175 | 175 |
Q | Wheel Size | 700C | 700C | 700C | 700C | 700C |
-
SizesS, M, M/L, L, XL
-
ColoursBlack Diamond/Airglow
-
FrameAdvanced-Grade Composite, 12mm thru-axle, disc
-
ForkAdvanced-Grade Composite, full-composite OverDrive 2 steerer, disc
-
ShockN/A
-
HandlebarGiant Contact SLR
-
GripsStratus Lite 3.0
-
StemGiant Contact SL
-
SeatpostGiant D-Fuse SLR, composite, -5/+15mm offset
-
SaddleGiant Approach SL
-
PedalsN/A
-
ShiftersSRAM Force eTap AXS, 1x12
-
Front DerailleurN/A
-
Rear DerailleurSRAM Force eTap AXS
-
BrakesSRAM Force eTap AXS hydraulic, SRAM CenterLine rotors [F]160mm, [R]140mm
-
Brake LeversSRAM Force eTap AXS hydraulic
-
CassetteSRAM Force, 12-speed, 10x36
-
ChainSRAM Force D1
-
CranksetSRAM Force D1 DUB, 40t
-
Bottom BracketSRAM DUB, press fit
-
RimsGiant CXR 1 Carbon Disc WheelSystem
-
Hubs[F] Giant AR alloy, CenterLock, 12mm thru-axle, [R] Giant AR alloy, DT350 36t ratchet system, CenterLock, 12mm thru-axle
-
SpokesSapim CX-Ray
-
TiresMaxxis All-Terrene, 700x33c, tubeless
-
ExtrasGiant 1x chainguide, tubeless prepared, 45mm max tyre size
-
WeightThe most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
