Product details
All the playfulness you need for a massive grin
The balanced geometry of the JAM² 6.8 gives you unlimited trail fun, up and down. It handles intuitively downhill, while uphill you can tackle any climb thanks to even weight distribution and plenty of traction on the front wheel. Countless hours of test riding have gone into the specific tune of the JAM² . As a result, the JAM² 6.8's shock tune is as firm, reactive and sporty as it gets without compromising on traction. You can find our recommendations for the perfect suspension set-up in the FAQ on the JAM² family page.
Full control when things get dicey
If you ride the JAM² 6.8 hard, close calls are unavoidable. Soft, 2.6-inch-wide trail tyres with a strong casing and powerful brakes paired with 200 mm brake discs enable you to ride at full speed with peace of mind. And even off the trail, you have full control and always know where your bike is thanks to the integrated mounting options for an Airtag or Chipolo.
The battery size that's right for you
The JAM² 6.8 is available with both the compact 600 Wh battery and the larger 800 Wh battery. Both are removable and differ only in appearance, with a larger cover for the down tube. Please ask your local FOCUS dealer for more information. In addition, the JAM² 6.8 is compatible with the 250 Wh range extender in all sizes. That adds up to four battery configurations ranging from 600 to a whopping 1050 Wh. This means you'll always have enough juice for the renowned and reliable Bosch Performance Line CX e-drive – and maximum trail fun.
Geometry
| S | M | L | XL | ||
|---|---|---|---|---|---|
| Size in mm | 390 | 420 | 440 | 460 | |
| Handlebar width | 800 | 800 | 800 | 800 | |
| Stem length | 40 | 40 | 40 | 40 | |
| Crank length | 165 | 165 | 165 | 165 | |
| A | Seat tube length | 390 | 420 | 440 | 460 |
| B | Top tube length | 576 | 608 | 636 | 668 |
| C | Head angle (°) | 65 | 65 | 65 | 65 |
| D | Seat angle (°) | 76.5 | 76.5 | 76.5 | 76.5 |
| E | Chainstay length | 450 | 450 | 450 | 450 |
| F | Bottom bracket drop | 25 | 25 | 25 | 25 |
| G | Head tube length | 110 | 120 | 130 | 140 |
| H | Fork length | 575 | 575 | 575 | 575 |
| I | Fork offset | 44 | 44 | 44 | 44 |
| J | Wheelbase | 1205 | 1239 | 1268 | 1303 |
| K | Stack | 630 | 639 | 648 | 657 |
| L | Reach | 425 | 455 | 480 | 510 |
| M | Standover height | 783 | 783 | 783 | 783 |
Specification
Frame
7005 hydroformed aluminium, 150 mm F.O.L.D. kinematics, 148x12 mm thru axle, Post Mount 180 mm
Special Features
Tool bag (exluding size S & M), Hidden AirTag or Chipolo holder
Fork
Rock Shox Lyrik Select, Debon Air+, Charger RC, 160 mm
Shock
Rock Shox Super Deluxe Select, DebonAir+, 150 mm
Motor
Bosch Performance Line CX, 85 NM, 100 NM update via Flow App available summer
Battery
Bosch PowerTube Li-Ion (600 Wh)
Display & Remote
Bosch Purion 200
Shifter
SRAM Eagle 70
Rear derailleur
SRAM Eagle 70, 12-speed
Cassette
SRAM GX Transmission, 10-52T
Chain
Sram Eagle 70
Crankset
Samox, 165 mm
Chainring
SRAM T-Type, 36 T
Handlebar
Alloy, width: 800 mm, rise: 30 mm
Grips
VP Lock-On Grips
Stem
FOCUS C.I.S. 2.0, 40 mm
Headset
ACROS ZS56/ZS66 (ICR), FOCUS C.I.S. Integrated
Saddle
Focus
Seatpost
Post Moderne DP-212, S / M /L / XL: 125 / 170 / 170 / 200 mm, 34,9 mm
Brakes front | rear
SRAM DB8, 4-piston | SRAM DB8, 4-piston
Disc brake rotors
SRAM Centerline, front: 200 mm / rear: 200 mm
Rim front
Raceface AR-30, alloy, 29"
Rim rear
Raceface AR-30, alloy, 29"
Front hub
Formula DC-611
Rear hub
Formula DC-648
Tyres front | rear
Schwalbe Albert, Super Trail, ADDIX Ultra Soft, 29 x 2,6" | Schwalbe Albert, Super Trail, ADDIX Soft, 29 x 2,6"
Weight
24.8 kg (600 Wh)
Permissible system weight
150 kg
